Building Angular 6|7 Universal Apps (Server Side Rendering)

Building Angular 6|7 Universal Apps (Server Side Rendering)

Angular 6|7 allows developers to build modern SPAs (or Single Page Apps) which are considered the modern apps of our time. SPAs have many advantages over old traditional apps such as:

  • The client is responsible of doing most rendering. For the server its major role is serving the app files to the client.
  • No page refresh.
  • No need for reaching the server for every action.
  • Easy navigation between different pages.
  • Improved performance.
  • No extra requests to server to load new pages.
  • User friendliness etc.

As seen, SPAs have a lot of advantages, particularly an improved User Experience, which is what matters the most when building apps. But they have a major SEO problem, they can't be indexed by Search engines.

This is not totally correct! Since Google can index and render JavaScript apps but not all engines are as advanced as Google. Also social networks such as Facebook only understands server rendered HTML. You can easily notice this when trying to share an SPA website on Facebook or other social networks. The social network won't be able to recognize the meta content of your shared page like the title.

So to make sure, every search engine and social network out there can recognize your website content, you need to implement the old server side rendering or create what we call Universal apps which are SPAs with server side rendering.

Getting started with Angular Universal

Angular Universal is a technology that allows server side rendering for Angular apps.

Thanks to Angular universal, you can build apps that have the best features of both worlds such as:

  • Performance: Since your app is rendered on the server, first time users will quickly see a rendered view without waiting for the client to complete rendering.
  • SEO friendliness: Many search engines and social networks can read only plain HTML so to optimize your website for these engines you need to have server side rendering
  • Social networks friendliness: By enabling server side rendering, social media websites can correclty display previews of your apps or websites when sharing links.

Starting from Angular 4.0.0 the majority of Angular Universal code is located in the @angular/platform-server package.

Creating an Angular 6 Project

Now let's create an Angular 6 demo project to show how to add server side rendering.

You need to have Angular CLI 6 installed then open your terminal and run:

$ ng new angular-universal-demo
$ cd angular-universal-demo

Next install Angular Universal located in the @angular/platform-server package:

$ npm install --save @angular/platform-server

You also need to install the @angular/animations package otherwise you'll get errors:

$ npm install --save @angular/animations

Now, open the src/app/app.module.ts file then update it to reflect these changes:

    import { BrowserModule } from '@angular/platform-browser';
    import { NgModule } from '@angular/core';
    import { FormsModule } from '@angular/forms';
    import { HttpModule } from '@angular/http';

    import { AppComponent } from './app.component';

    @NgModule({
    declarations: [
        AppComponent
    ],
    imports: [
        BrowserModule.withServerTransition({appId: 'angular-universal-demo'}),
        FormsModule,
        HttpModule
    ],
    providers: [],
    bootstrap: [AppComponent]
    })
    export class AppModule { }

Now you need to add a server app module so go ahead and create a new TypeScript file src/app/app.server.module.ts then copy and paste the following code:

    import { NgModule } from '@angular/core';
    import { ServerModule } from '@angular/platform-server';
    import { AppModule } from './app.module';
    import { AppComponent } from './app.component';

    @NgModule({
    imports: [
        ServerModule,
        AppModule
    ],
    bootstrap: [AppComponent]
    })
    export class AppServerModule { }

Next create an Express server in the src/server.ts file:

    import 'reflect-metadata';
    import 'zone.js/dist/zone-node';
    import { platformServer, renderModuleFactory } from '@angular/platform-server'
    import { enableProdMode } from '@angular/core'
    import { AppServerModuleNgFactory } from '../dist/ngfactory/src/app/app.server.module.ngfactory'
    import * as express from 'express';
    import { readFileSync } from 'fs';
    import { join } from 'path';

    const PORT = 4000;

    enableProdMode();

    const app = express();

    let template = readFileSync(join(__dirname, '..', 'dist', 'index.html')).toString();

    app.engine('html', (_, options, callback) => {
    const opts = { document: template, url: options.req.url };

    renderModuleFactory(AppServerModuleNgFactory, opts)
        .then(html => callback(null, html));
    });

    app.set('view engine', 'html');
    app.set('views', 'src')

    app.get('*.*', express.static(join(__dirname, '..', 'dist')));

    app.get('*', (req, res) => {
    res.render('index', { req });
    });

    app.listen(PORT, () => {
    console.log(`listening on http://localhost:${PORT}!`);
    });

Open the src/tsconfig.app.json file and exclude the server.ts file:

    {
    "extends": "../tsconfig.json",
    "compilerOptions": {
        "outDir": "../out-tsc/app",
        "module": "es2015",
        "baseUrl": "",
        "types": []
    },
    "exclude": [
        "server.ts",
        "test.ts",
        "**/*.spec.ts"
    ]
    }

Next, open the tsconfig.json and add angularCompilerOptions:

    {
    "compileOnSave": false,
    "compilerOptions": {
        "outDir": "./dist/out-tsc",
        "baseUrl": "src",
        "sourceMap": true,
        "declaration": false,
        "moduleResolution": "node",
        "emitDecoratorMetadata": true,
        "experimentalDecorators": true,
        "target": "es5",
        "typeRoots": [
        "node_modules/@types"
        ],
        "lib": [
        "es2016",
        "dom"
        ]
    },
    "angularCompilerOptions": {
        "genDir": "./dist/ngfactory",
        "entryModule": "./src/app/app.module#AppModule"
    }
    }

Installing ts-node and Running your Demo Server

Now you need to install ts-node via npm:

$npm install -D ts-node

Next, open the package.json file and add these two scripts:

    "prestart": "ng build --prod && ngc",
    "start": "ts-node src/server.ts"

You can now test your demo by running

$ npm run start

You should be able to visit http://localhost:4000 with your browser to see your old message app works!.

You can find the source code of this demo at GitHub

Conclusion

We have seen how to build Universal SPA application with Angular 6 which can be rendered on the server side.
